Introduction

E-ink displays are increasingly popular because they use very little power and can display information without any backlighting. This makes them ideal for projects where power consumption is a concern. However, interfacing them with microcontrollers can be challenging for beginners.

In this article, we’ll explore how to interface a “1.54” E-ink Display” with an Arduino board and display text and graphics on it.

What is E-ink Display?

E-ink (electronic ink) display is a type of electronic paper display technology used for displaying static images and text. It uses a process called electrophoresis to display content on the screen. The display consists of tiny capsules filled with positively charged white particles and negatively charged black particles suspended in a clear fluid. When an electric field is applied, the particles move to either the top or bottom of the capsule, creating the illusion of black or white pixels on the screen. Unlike traditional LCD displays, E-ink displays don’t require a backlight, making them energy-efficient and easy to read in direct sunlight.

Buy from Amazon

Hardware Components

To interface an E-ink Display with Arduino, you’ll need the following hardware components to get started:

Components	Value	Qty
Arduino UNO	–	1
USB Cable Type A to B	–	1
DC Power for Arduino	–	1
E-ink Display	1.54inch	1
Jumper Wires	–	1

E-ink Display Pinout

Pin Label	Pin Type	Description
VIN	Power	This is the input power pin. You can supply 5 V from the Arduino here. There is a 3.3 V linear voltage regulator on the display module. This pin serves as the input for the regulator.
3V3	Power	This is the output of the voltage regulator. The 3.3 V powers the display controller IC. You can also use this to power other modules, but ensure that the current consumption is kept below the regulator voltage rating.
GND	Power	Ground connection pin.
SCK	Signal	SPI Clock – Clock Pin of the serial peripheral interface
MISO	Signal	SPI MISO – Master In Slave Out pin of the Arduino. This is the input pin of the Display controller and the output pin of the Arduino.
MOSI	Signal	SPI MOSI – Master Out Slave In – This is the Arduino output pin and input pin for the display controller.
ECS	Signal	E-ink Chip Select
D/C	Signal	E-ink data command
SRCS	Signal	SRAM chip select
SDCS	Signal	SD Card chip select
RST	Signal	E-ink reset
BUSY	Signal	E-ink Busy signal
ENA	Signal	Enable pin. This is connected to the Enable pin of the 3.3 V regulator. You can drive the pin Low to save Power when you have to. When you disable the display controller, the display RAM and the SD Card (if present) will all get disabled. You have to reinitialize the board again.

E-ink Display Circuit

Make connections according to the circuit diagram given below.

Wiring / Connections

Arduino	E-ink Display
5V	VIN
GND	GND
D9	ECS
D10	DC
D6	SRCS
D8	RES
D7	BUSY
D5	SDCS
ICSP	SCK
ICSP	MISO
ICSK	MOSI

Installing Arduino IDE

First, you need to install Arduino IDE Software from its official website Arduino. Here is a simple step-by-step guide on “How to install Arduino IDE“.

Installing Libraries

Before you start uploading a code, download and unzip the following libraries at /Program Files(x86)/Arduino/Libraries (default), in order to use the sensor with the Arduino board. Here is a simple step-by-step guide on “How to Add Libraries in Arduino IDE“.

Adafruit_ThinkInk.h

Code

Now copy the following code and upload it to Arduino IDE Software.

#include "Adafruit_ThinkInk.h"

#define EPD_DC      10 // can be any pin, but required!
#define EPD_CS      9  // can be any pin, but required!
#define EPD_BUSY    7  // can set to -1 to not use a pin (will wait a fixed delay)
#define SRAM_CS     6  // can set to -1 to not use a pin (uses a lot of RAM!)
#define EPD_RESET   8  // can set to -1 and share with chip Reset (can't deep sleep)

// 1.54" 152x152 Tricolor EPD with ILI0373 chipset
//ThinkInk_154_Tricolor_Z17 display(EPD_DC, EPD_RESET, EPD_CS, SRAM_CS, EPD_BUSY);

// 1.54" 152x152 Tricolor EPD with SSD1680 chipset
//ThinkInk_154_Tricolor_RW display(EPD_DC, EPD_RESET, EPD_CS, SRAM_CS, EPD_BUSY);

// 1.54" 200x200 Tricolor EPD with SSD1681 chipset
//ThinkInk_154_Tricolor_Z90 display(EPD_DC, EPD_RESET, EPD_CS, SRAM_CS, EPD_BUSY);

// 2.13" Tricolor EPD with SSD1680 chipset
//ThinkInk_213_Tricolor_RW display(EPD_DC, EPD_RESET, EPD_CS, SRAM_CS, EPD_BUSY);

// 2.13" Tricolor EPD with IL0373 chipset
//ThinkInk_213_Tricolor_Z16 display(EPD_DC, EPD_RESET, EPD_CS, SRAM_CS, EPD_BUSY);

// 2.7" Tricolor Featherwing or Breakout with IL91874 chipset
//ThinkInk_270_Tricolor_C44 display(EPD_DC, EPD_RESET, EPD_CS, SRAM_CS, EPD_BUSY);

// 2.7" Tricolor Featherwing or Breakout with EK79686 chipset
//ThinkInk_270_Tricolor_Z70 display(EPD_DC, EPD_RESET, EPD_CS, SRAM_CS, EPD_BUSY);

// 2.9" Tricolor Featherwing or Breakout with IL0373 chipset
ThinkInk_290_Tricolor_Z10 display(EPD_DC, EPD_RESET, EPD_CS, SRAM_CS, EPD_BUSY);
// 2.9" Tricolor Featherwing or Breakout with UC8151D chipset
//ThinkInk_290_Tricolor_Z13 display(EPD_DC, EPD_RESET, EPD_CS, SRAM_CS, EPD_BUSY);
// 2.9" Tricolor Featherwing or Breakout with SSD1680 chipset and negative offset
//ThinkInk_290_Tricolor_Z94 display(EPD_DC, EPD_RESET, EPD_CS, SRAM_CS, EPD_BUSY);

//ThinkInk_420_Tricolor_RW display(EPD_DC, EPD_RESET, EPD_CS, SRAM_CS, EPD_BUSY);
//ThinkInk_420_Tricolor_Z21 display(EPD_DC, EPD_RESET, EPD_CS, SRAM_CS, EPD_BUSY);


void setup() {
  Serial.begin(115200);
  while (!Serial) { delay(10); }
  Serial.println("Adafruit EPD full update test in red/black/white");
  display.begin(THINKINK_TRICOLOR);
}

void loop() {
  Serial.println("Banner demo");
  display.clearBuffer();
  display.setTextSize(3);
  display.setCursor((display.width() - 144)/2, (display.height() - 24)/2);
  display.setTextColor(EPD_BLACK);
  display.print("Tri");
  display.setTextColor(EPD_RED);
  display.print("Color");
  display.display();

  delay(15000);

  Serial.println("Color rectangle demo");
  display.clearBuffer();
  display.fillRect(display.width()/3, 0, display.width()/3, display.height(), EPD_BLACK);
  display.fillRect((display.width()*2)/3, 0, display.width()/3, display.height(), EPD_RED);
  display.display();

  delay(15000);

  Serial.println("Text demo");
  // large block of text
  display.clearBuffer();
  display.setTextSize(1);
  testdrawtext("Lorem ipsum dolor sit amet, consectetur adipiscing elit. Curabitur adipiscing ante sed nibh tincidunt feugiat. Maecenas enim massa, fringilla sed malesuada et, malesuada sit amet turpis. Sed porttitor neque ut ante pretium vitae malesuada nunc bibendum. Nullam aliquet ultrices massa eu hendrerit. Ut sed nisi lorem. In vestibulum purus a tortor imperdiet posuere. ", EPD_BLACK);
  display.display();

  delay(15000);

  display.clearBuffer();
  for (int16_t i=0; i<display.width(); i+=4) {
    display.drawLine(0, 0, i, display.height()-1, EPD_BLACK);
  }

  for (int16_t i=0; i<display.height(); i+=4) {
    display.drawLine(display.width()-1, 0, 0, i, EPD_RED);
  }
  display.display();

  delay(15000);
}


void testdrawtext(const char *text, uint16_t color) {
  display.setCursor(0, 0);
  display.setTextColor(color);
  display.setTextWrap(true);
  display.print(text);
}
The code snippet below shows the pin mapping. The pin mapping can be updated based on your actual hardware connections.

#define EPD_DC      10 // can be any pin, but required!
#define EPD_CS      9  // can be any pin, but required!
#define EPD_BUSY    7  // can set to -1 to not use a pin (will wait a fixed delay)
#define SRAM_CS     6  // can set to -1 to not use a pin (uses a lot of RAM!)
#define EPD_RESET   8  // can set to -1 and share with chip Reset (can't deep sleep)

Code Explanation

This is an Arduino code that controls an E-ink display.

The first few lines of code define the pins that will be used to communicate with the display, including a pin for data/command (EPD_DC), chip select (EPD_CS), and a pin to check if the display is busy (EPD_BUSY). It also sets the SRAM_CS and EPD_RESET pins for use with specific displays.

Next, several different E-ink display models are instantiated using the Adafruit_ThinkInk library, each with their own set of parameters.

In the setup() function, the serial connection is initialized, and the display is initialized with the begin() method. In the loop() function, there are several examples of using the display, including displaying text, drawing lines, and filling rectangles.

Finally, the testdrawtext() the function is defined, which draws a block of text to the display.

Applications

Here are some applications of E-ink displays:

E-book readers
Smartwatches and fitness trackers
Electronic shelf labels
Digital signage and advertising displays
Wearable technology
Industrial displays
Medical equipment displays
Electronic price tags for retail stores
Public transportation information displays
Smart home interfaces
Smart luggage tags
Point-of-sale displays
Mobile payment devices
Electronic newspapers and magazines

Conclusion

An E-ink display with an Arduino board may seem daunting at first, but with the right approach, it can be a straightforward process. By following the steps outlined in this article, you can create your own E-ink display projects and take advantage of the low-power and versatile nature of these displays.
